- The engine is perfectly matched to the transmission chain and hydraulic system, for more efficiency and less wastage.
- The hydraulic system has a dual-pump confluence with steering always in priority, reducing energy loss.
- A/C with big cooling capacity, adding air from back and bottom of machine for all-round effect.
- Single layer radiator and big range fin spacing for high efficiency and easy maintenance.
|Operating Weight||20,287 kg|
|Bucket Capacity||3.7 m³|
|Gross Power||180 kW (241 hp / 245 ps) @ 2,200 rpm|
|Net Power||168 kW (225 hp / 228 ps) @ 2,200 rpm|
|Rated Load||6,500 kg|
|Total Cycle Time||9.3 s|
|Tipping Load-full Turn||14,614 kg|
|Bucket Breakout Force||178 kN|
|Dump Clearance, Full Height Discharge||3,303 mm|
|Dump Reach, Full Height Discharge||1,072 mm|
|Emissions||EPA Tier 3 / EU Stage III|
|Length with Bucket Down||8,849 mm|
|Width over Tires||2,980 mm|
|Cab Height||3,550 mm|
